DESCRIPTION:
· 1
console controls 2 computers – non-powered
· Most compact KVM switch with molded cables for computer connection.
· Compatible with all operating platforms
· Supports Microsoft IntelliMouse and the scrolling wheel on most mice
· Easy to install – No software required – connecting cables to
the computers is all it takes
· Easy to operate – PC selection via hotkey – auto scan function
to monitor computer operation7. LED display for easy status monitoring
· Caps Lock, Num Lock, and Scroll Lock states are saved and restored when switching
· Hot pluggable – add or remove computers for easy maintenance
· Keyboard and mouse emulation for error free PC booting11.
· Patented VSE (Video Signal Enhancement) technology for rich 32 bit color--up
to 1920*1440;DDC,DDC2,DDC2B
SPECIFICATIONS:
|
Function |
CS-62BAT |
| PC Connection |
2 |
| Port Selection |
Hot Keys |
| LEDs |
Selected |
2 |
| Emulation |
Keyboard |
PS/2; AT |
| Mouse |
PS/2 |
| Connectors |
Keyboard |
1 x 6 pin mini-DIN Female
(PS/2)-Console |
| 2 x 6 pin mini-DIN Female (PS/2)-CPU
Port |
| Mouse |
1 x 6 pin mini-DIN Female
(PS/2)-Console |
| 2 x 6 pin mini-DIN Female (PS/2)-CPU
Port |
| Video |
1 HDB-15 Female (Std.
VGA/SVGA)-Console |
| 2 HDB-15 Male (Std. VGA/SVGA)-CPU
Port |
| VGA Resolution |
1920 x 1440 (Max.); DDC, DDC2, DDC2B |
| Scan Interval |
3, 5, 10, 20 sec. |
| Housing |
Plastic |
| Weight |
162 g |
| Dimensions |
120 x 50 x 25 mm (L x W x H) |
| Built-in Cable Length |
4 feet
(1.2 meter) |
|
